Pressure transducer SITRAN P200 for Pressure and absolute pressure for general applications Conformity error type 0.25 Percent Wetted parts parts: Ceramics and stainless steel and sealing material Material of non-wetted materials: stainless steel Measuring range for absolute pressure: 0 to 6 bar abs.. overload pressure 15 bar abs. Output signal: 0 to 10 V three-wire input Auxiliary power: 12 to 33 V DC Without explosion protection Electrical connection: Connector according to EN 175301-803-A. Stuffing box thread M16 (with coupling) Process connection: G1/2" external according to EN837-1 (1/2"-BSP external); (Standard for metric pressure ranges mbar. bar) Sealing material between Sensor and housing: Viton (FPM. standard) Standard version
Circuit breaker size S3 for motor protection. Class 10 A-release 28...40 A Short-circuit release 520 A Screw terminal Increased switching capacity
Front connector module with flat ribbon Cable connection for digital 16 I/O modules of the S7-300. Power supply over Spring terminals
