SIMATIC S7-1500. ANALOG INPUT MODULE AI 4 X U/I/RTD/TC. 16 BITS OF RESOLUTION. ACCURACY 0.3 %; 4 CHANNELS IN GROUPS OF 4; COMMON MODE VOLTAGE APPR. 10 V; DIAGNOSIS. PROCESSALARMS INCL. FRONT CONNECTOR PUSH-IN. FEEDING ELEMENT. SHIELDING ELE- MENT. SHIELDING CLAMP
SIMATIC S7-1500. ANALOG OUTPUT MODULE AQ 4 X U/I ST; 16 BITS OF RESOLUTION. ACCURACY 0.3 %; 4 CHANNELS IN GROUPS OF 4; DIAGNOSIS. SUBSTITUTE VALUE INCL. INFEED ELEMENT. SHIELD CLAMP AND SHIELD TERMINAL
SIMATIC S7-1500. ANALOG OUTPUT MODULE AQ 8 X U/I HS 16 BITS OF RESOLUTION. ACCURACY 0.3 %. 8CHANNELS IN GROUPS OF 8. DIAGNOSIS. SUBSTITUTE VALUE 8 CHANNELS IN 0.125 MS INCL. INFEED ELEMENT. SHIELD CLAMP AND SHIELD TERMINAL
SIMATIC S7-1500. ANALOG IN-/OUTPUT MODULE AI4XU/I/R/RTD/TC; 4 CHANNELS IN GROUPS OF 4 PROCESSALARMS; DIAGNOSIS AQ2XU/I; 2 CHANNELS IN GROUPS OF 2; SUBSTITUTE VALUE; DIAGNOSIS; COMMON-MODE-VOLTAGE APPR. 10V; 16BIT; ACCURACY 0.3% INCL. FRONT CONNECTOR PUSH IN. FEEDING ELEMENT. SHIELDING ELE- MENT. SHIELDING CLAMP
SIMATIC S7-1500. SYSTEM POWER SUPPLY PS 25W 24V DC. SUPPLIES THE OPERATING VOLTAGE FOR THE S7-1500 VIA THE BACKPLANE BUS
SIMATIC ET 200MP PROFINET IO-DEVICE INTERFACEMODULE IM 155-5 PN FOR ET 200MP ELEKTRONIKMODULES; UP TO 12 IO-MODULES SHARED DEVICE UP TO 2 IO-CONTROLLER; MRP; FW-UPDATE; I&M0...3;
SIMATIC ET 200MP. PROFINET IO-DEVICE INTERFACEMODULE IM 155-5 PN ST FOR ET 200MP ELEKTRONIKMODULES; UP TO 12 IO-MODULES WITHOUT ADDITIONAL PS; UP TO 30 IO- MODULES WITH ADDITIONONAL PS SHARED DEVICE; MRP; IRT >=0.25MS; ISOCHRONICITY FW-UPDATE; I&M0...3; FSU WITH 500MS
SIMATIC ET 200MP. PROFINET IO-DEVICE INTERFACEMODULE IM 155-5 PN HF FOR ET 200MP ELEKTRONIKMODULES; UP TO 12 IO-MODULES WITHOUT ADDITIONAL PS; UP TO 30 IO- MODULES WITH ADDITIONONAL PS SHARED DEVICE; MRP; IRT >=0.25MS; ISOCHRONICITY FW-UPDATE; I&M0...3; FAST STARTUP S2 REDUNDANCY; SHARED DEV. WITH 4 CONTROLLER
SIMATIC ET 200MP. PROFIBUS INTERFACE MODULE IM155-5 DP ST FOR MAX. 12 S7-1500 MODULES
SIMATIC S7-1500. DIGITAL INPUT MODULE DI 16 X 24...125V UC HF. 16 CHANNELS IN GROUPS OF 1; INPUT DELAY 0.05 ... 20MS; INPUT TYPE 3 (IEC 61131); DIAGNOSIS. PROCESSALARMS
SIMATIC S7-1500. DIGITAL OUTPUT MODULE DQ16x24..48VUC/125V DC/0.5A ST; 16 CHANNELS IN GROUPS OF 1. 0.5A PER GROUP; SUBSTITUTE VALUE; PLEASE NOTE DERATING
SIMATIC S7-1500. DIGITAL OUTPUT MODULE DQ 16 X 230VAC / 1A ST.TRIAC; 16 CHANNELS IN GROUPS OF 2. 2A PER GROUP; SUBSTITUTE VALUE
